Description
Features:
- Capable of easy 2 wire installation, but requires a three–wire system to operate the oscillation mechanism independent of the fan blades
- Includes hand-balanced metal fan blades and safety cages
- Constructed from cast aluminum and heavy stamped steel
- Includes 3-Speed RF remote control
- Covered by manufacturer’s limited lifetime warranty
Dimensions:
- Height: 14-1/2″
- Width: 16″
- Product Weight: 16 lbs.
- Backplate Depth: 2″
- Backplate Width: 6″
Blade Specifications:
- Number of Blades: 3
- Blade Span: 16″
- Blades Included: Yes
- Reversible Blades: No
- Fan Blade Material: Metal
Motor Specifications:
- Speeds: 3
- CFM (High): 1600
- CFM (Med): 1130
- Motor Wattage: 17
- Energy Efficiency (CFM / Watt): 57
- RPM: 1520
- Reversible Motor: Yes
- Voltage: 110-220 volts
|
Backplate Depth |
2in. |
|
Backplate Diameter |
5.5in. |
|
Backplate Width |
6in. |
|
Blade Pitch |
31Degrees |
|
Blade Span |
16in. |
|
CFM |
1600 |
|
Depth |
19.5in. |
|
Height |
14.5in. |
|
Nominal Height |
15in. |
|
Nominal Width |
16in. |
|
Product Weight |
12lbs. |
|
Width |
16in. |
Dimensions and Measurements
|
Backplate Depth |
2in. |
|
Backplate Diameter |
5.5in. |
|
Backplate Width |
6in. |
|
Blade Pitch |
31Degrees |
|
Blade Span |
16in. |
|
CFM |
1600 |
|
Depth |
19.5in. |
|
Height |
14.5in. |
|
Nominal Height |
15in. |
|
Nominal Width |
16in. |
|
Product Weight |
12lbs. |
|
Width |
16in. |
Included Components
|
Blades Included |
Yes |
|
Downrod(s) Included |
No |
Included Components
|
Blades Included |
Yes |
|
Downrod(s) Included |
No |
Characteristics and Features
|
Blade Finish |
Black, Bronze, Nickel |
|
Fan Blade Material |
Metal |
|
Light Kit Compatible |
No |
|
Material |
Aluminum, Steel |
|
Number of Blades |
3 |
|
Reversible Motor |
Yes |
|
Theme |
Contemporary |
|
Control Type |
Remote |
|
Fan Type |
Hanging |
|
Low Ceiling Adaptable |
Yes |
|
Motor |
DC Motor |
|
Reversible Blades |
No |
|
Sloped Ceiling Compatible |
No |
Electrical and Operational Information
|
Energy Efficiency (CFM / Watt) |
57 |
|
RPM (High) |
1520 |
|
Speeds |
3 |
|
Voltage Type |
Commercial Voltage (125V+), Line Voltage (110-120V) |
Electrical and Operational Information
|
Energy Efficiency (CFM / Watt) |
57 |
|
RPM (High) |
1520 |
|
Speeds |
3 |
|
Voltage Type |
Commercial Voltage (125V+), Line Voltage (110-120V) |
Warranty and Product Information
|
Certifications |
UL |
|
Country Of Origin |
China |
|
Made in America |
Yes |
Warranty and Product Information
|
Certifications |
UL |
|
Country Of Origin |
China |
|
Made in America |
Yes |
